Channels
6
Pipe Material
PC Clear (UL94 V-0)
Shield Material
PA66 black Ul94 V0
ESD Protection
< 8 kV
Operating Temperature
−40 °C ~ +90 °C
Pitch
N/A
LED Suggestion
LxWxH<4.70x4.60x2.80mm
TAD17
TAD17 is a single-row PCB light guide designed for clear multi-channel LED indication. With a large Ø4.6 mm optical interface, it provides enhanced visibility for status indicators in industrial equipment. The integrated black PA66 shield structure helps isolate adjacent light channels, ensuring clear and well-defined signal indication.
PCB Mounting Hole
ø2.50mm
Mounting Method
Press-Fit
Mounting Type
PCB Mount
Lens Dimension
ø6.30×2.90mm
Lens Shape
Round
Alignment
Horizontal
Lens Optics
Flat
Lens Finish
Diffused
