Channels
2
Pipe Material
PC Clear (UL94 V-0)
Shield Material
PC+ABS White (UL94 V-0)
ESD Protection
< 8 kV
Operating Temperature
−40 °C ~ +90 °C
Pitch
5.00mm
LED Suggestion
LxWxH<4.60x4.60x2.20mm
TAA11
TAA11 is a horizontal dual-channel PCB-mounted light guide designed for compact LED indication in electronic equipment. Its press-fit mounting ensures stable alignment between the PCB LEDs and the visible indicator points, while the diffused round lenses provide clear and uniform status display. The 5.0 mm pitch design makes it suitable for PLC modules, control panels, and industrial electronics.
PCB Mounting Hole
Ø2.30mm
Mounting Method
Press-Fit
Mounting Type
PCB Mount
Lens Dimension
Ø3.00 × 4.50 mm
Lens Shape
Round
Alignment
Horizontal
Lens Optics
Flat
Lens Finish
Diffused
